Company Capability – One Stop Solution
R&D – Technical Guarantee to Provide One Stop Solution
A group of experienced R&D engineers with expertise in material design and manufacturing, process engineering and automation Accounts for 28% of total office employees
Active University/Company Cooperation
Material research, design and testing partner
Performance Test
Well equipped lab for all material categories
After Service
Global service & technical support, including Korea, China, Taiwan, India, Japan & USA
Lab Capability
SG Test Lab – Label & Tape
Testing items
Ordinary test
-Dimensions
-Initial adhesion
-Holding power & SAFT
-Peel strength (H/LT & HH)
Reliability Test
-Rubber abrasion test
-Grinding wheel abrasion test
- Solvent test
-THT-printing test
-Reflow soldering test
-Heat Soak & Thermal shock test
Environmental friendly test
- RoHS test
Auto Rolldown Tester KeJian KJ-6012C
Holding Power & SAFT Tester JinGe PT-6012L-10
Quadratic Element Acuick 320M
Initial Adhesion Tester YuHong YH-9407-1
Adhesive Strength Tester KeJian KJ-1065A
Heat Soak Tester JiangKai GDW-1
H/LT & HH Peel/ Push out Tester KeJian KJ-1067
Thermal Shock Haida 100k40
SG Test Lab – Film & Tape
Testing items
Ordinary test
-Thickness and Dimensions
-Initial adhesion
-Holding power
-Peel strength
Reliability Test
- Water-proof test
- Flame retardant test
-High and low temperature
environment test
Environmental test
- RoHS test
UV Aging Chamber ShunNuo ZN-P
Salt Spray Tester JiangKai JK-YW-60
Transmittance and Haze Tester INESA WGT-S
Rubber and Alcohol Abrasion Tester SG Machine
RoHS Test Machine SKYRAY EDX1800B
Tumbling Tester JiangKai GT-724F
Water-proof Tester Skytest PX7
Horizontal and Vertical Burning Tester Skytest SKY3004
SG Test Lab – Special Equipment for Mini Led Die Assembly Process
Testing items
-UV radiation
-Dynamic Axial Cycle
-Push Test
-Color Spectrum test
-Semiautomatic Die-Spread test
-DMA test
-UV energy test
-OD value test
LED UV Lamp FuTansi UVOV81T
Dynamic Axial Cycle Test-SG Machine
Push Test-SG Machine
Color Spectrum illuminometer Hopocolor OHSP350s
Semiautomatic Die-Spread Machine SG Machine
DMA Mettler DMA1
UV Energy Meter LinShang LS128
Optical Density Meter LinShang LS117
SG Test Lab - Conductive Tape & Foam
Testing items
Ordinary test
-Thickness and Dimensions
-Tensile Strength
-X,Y/Z resistance
-Density
Reliability Test
-Abrasion test
-Reflow soldering test
-Rebound rate test
-Compression set test
-High and low temperature environment test
Environmental test
- RoHS test
Force and Resistance Testing Machine SG machine
Resistance Tester Rel RK2511N﹢
Compression Gauge HaiDa HD-F750
Dielectric Breakdown Voltage Tester DingLi LJC-50kv
Rebound Tester
DC Power MaiSheng MP10010D
SG Test Lab - Thermal materials
Testing items:
Ordinary test
-Thickness and Dimensions
-Density test
-Hardness test
-Thermal conductivity test
Reliability Test
-Application simulation test
-Breakdown Voltage test
-High and low temperature environment test
Environmental test
- RoHS test
Thermal Conductivity Tester XiangTan DRL-3
Cone Penetrometer HSY-269
Hardness Tester Teclock GS-754G
Simulation Test of Thermal Performance ZJ-1016
Thermal Imaging Camera FLIR I3
Density Tester MH-330APlus
SG Test Lab - EMI Materials
Testing items:
Ordinary test
-Thickness and Dimensions
-Density
-X,Y/Z resistance
-Permeability
-Absorbing efficiency
Reliability Test
-Application simulation test
-High and low temperature environment test
Environmental test
- RoHS test
Signal emitting device in simulation test for absorber material
Signal receiving device in simulation test for absorber material
Fully anechoic Chamber
10m semi-anechoic Chamber
